6.3 GDM memory module CP52M0
SIMATIC TDC hardware
System Manual, 08/2017, A5E01114865-AL
147
6.3.8
Technical specifications/performance features
Article number
GDM memory module CP52M0
6DD1660-0BF0
Memory
SRAM 2 MB
Interfaces
Serial service interface (X1)
• Transmission rate
RS232 interface (V.24)
• 19.2 Kbps
Digital outputs
Number 16
Electrical isolation
No
External power supply
• Rated voltage
• Perm. area
• short-term
• Current consumption, max., no load
24 V
20.4 V to 28.8 V
35 V (for max. 0.5 s)
40 mA
Output voltage range
• With 0 signal, max.
• With 1 signal, min.
3 V
ext. Supply voltage – 2.5 V
Output current
• With 0 signal, min.
• at 1 signal
• Rated value
• Valid range, max.
-20 µA
50 mA
100 mA
Delay time
100 µs
Switching frequency of outputs
With resistance load, max.
6 kHz
Short-circuit protection to
• Ground
• External power supply
yes
No
Short-circuit current, max.
250 mA
Total current of outputs (up to 60 °C)
16 x 50 mA
Limiting of inductive cut-off voltages
ext. Supply voltage +1 V
