Siemens SIMATIC TDC User Manual

Communication modules
6.6 CP53M0 coupling module
SIMATIC TDC hardware
System Manual, 08/2017, A5E01114865-AL
173
6.6.7
Pin assignments
FOC connectors X1 – X4
The FOC cables are connected by means of BFOC connector to the front connectors X1-X4.
For more information, refer to chapter “Areas of application”.
6.6.8
Technical specifications/performance features
Article number
CP53M0 coupling module
6DD1660-0BJ0
Memory
Communication memory SRAM, 128 KB
Buffer memory module
SDRAM, 8 MB
Note
If several CPxxMx are used in a rack, only the CPxxMx on the extreme left has the
buffer
memory function.
Interface
FOC interface
• Number
• Data transmission speed
• Code
2 (master mode)
1 (slave mode)
96 Mbps
5B/6B
Voltage, currents
Rated voltages at 25 °C
Typical current consumption
+5 V
0.3 A
3.3 V
0.5 A
