Interface module
7.6 Interface modules SU12 und SU13
SIMATIC TDC hardware
214 System Manual, 08/2017, A5E01114865-AL
Pin/terminal assignment X1/X2
The screw terminal numbers of X2 are identical with the numbering of ribbon cable
connector in accordance with the pin counting mode.
Minimum conductor cross-
section on terminal block X2
Maximum conductor cross section
on terminal block X2
SU13 0.2 mm² 1.5 mm².
Figure 7-13 SU12 circuit diagram
The components are described in chapter Function description (Page 212).
