Siemens SIMATIC TDC User Manual

Communication modules
6.1 CP50M1 communication module
SIMATIC TDC hardware
System Manual, 08/2017, A5E01114865-AL
129
Communication
Communication functions
• PROFIBUS DP coupling
• MPI coupling
• Buffer memory coupling
Voltage, currents
Rated voltages at 25 °C
Typical current consumption
+5 V DC (from rack)
1A
External battery (min. 2.2 V, typically 3.0 V) 350 nA
Power losses/fan
Typical power losses 5 W
Fan required
Yes, external fan
Dimensions
Number of slots required in the rack
1
Dimensions W x H x D [mm]
20 x 233 x 160
Weight
0.34 kg
