Siemens SINAMICS V90 User Manual

Control functions
7.6 Speed control (S)
SINAMICS V90, SIMOTICS S-1FL6
256 Operating Instructions, 04/2019, A5E36037884-007
Overview of important parameters
•
p29243
Position tracking activate
•
p29244
Absolute encoder virtual rotary revolutions
•
p29248
Mechanical gear: Numerator
•
p29249
Mechanical gear: Denominator
•
r2521[0]
LR position actual v
alue
7.6
Speed control (S)
7.6.1
Configuring speed setpoint
Eight sources in total are available for speed setpoint. You can select one of them with the
combination of digital input signals SPD1, SPD2 and SPD3:
Digital signal
Torque limit
SPD3
SPD2
SPD1
0
0
0
External analog speed setpoint (analog input 1)
0
0
1
Fixed speed setpoint 1 (p1001)
0 1 0 Fixed speed setpoint 2 (p1002)
0
1
1
Fixed speed setpoint 3 (p1003)
1
0
0
Fixed speed setpoint 4 (p1004)
1
0
1
Fixed speed setpoint 5 (p1005)
1
1
0
Fixed speed setpoint 6 (p1006)
1
1
1
Fixed speed setpoint 7 (p1007)
Refer to "DIs (Page 123)" for more information about the digital signals SPD1, SPD2 and
SPD3.
7.6.1.1
Speed control with external analog speed setpoint
In the S mode, when the digital input signals SPD1, SPD2 and SPD3 are all at low level (0),
analog voltage from the analog input 1 is used as the speed setpoint.
The analog voltage from the analog input 1 correponds to a parameterized speed value.
Default speed value is rated motor speed. The analog voltage of 10 V corresponds to the
maximum speed setpoint (V_max) and this maximum speed setpoint can be specified by
parameter p29060.
Parameter
Range
Default
Unit
Description
p29060 6 to 210000 3000 rpm Maximum analog speed setpoint correspond-
ing to 10 V

Siemens SINAMICS V90 Specifications

General

Power Range	0.05 kW to 7.0 kW
Protection Class	IP20
Communication	USS/Modbus RTU
Feedback	Incremental encoder
Input Voltage	1AC 200 V to 240 V, 3AC 380 V to 480 V
Control Modes	Position, Speed, Torque
Operating Temperature	0 °C to +40°C
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m above sea level
