Scale parameters and functions
8.16 DR 16 Weight simulation
SIWAREX WP251
Manual, 12/2015, A5E37203357A
105
8.15.2
Preset tare weight 1
Up to three tare weights can be entered. If a tare weight is to be applied, it must be enabled
with the corresponding command. The tare weights may not exceed the maximum values
specified in data record DR 3.
8.16
DR 16 Weight simulation
8.16.1
Overview
Specifying a weight value using data record DR 16 disables the measuring input of the
SIWAREX module and "simulates" a weight with the specified value. The SIWAREX module
must first be enabled for simulation mode in DR 3 and then switched to simulation mode with
command 3 ("Weight Simulation on"). Command 4 ("Weight Simulation off") switches the
module back to normal mode. In DR 30 Process State, a "Simulation mode" bit is available
that indicates whether or not the module is currently in simulation mode.
Procedure
● Enable simulation mode in DR 3
● Enter a weight value to be simulated in DR 16.
● Transfer DR 16 to the SIWAREX module
● Start the simulation using command "Weight simulation on (3)"
● Stop the simulation using command "Weight simulation off (4)"
Table 8- 16 Assignment of data record 16
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Data record
number
Contains no. of the data rec-
ord
USHORT 2 r 16 - - 1598
Length Data record length infor-
mation
USHORT 2 r 16 - - 1599
Application Information about which ap-
plication the data record
belongs to
USHORT 2 r 105 - - 1600
Version
identifier
Current data record version
information
USHORT 2 r 1 1 65635 1601
Weight simu-
lation speci-
fication
(Page 106)
Weight value specification
(only relevant if simulation
mode is enabled)
FLOAT 4 rw 0 - Max.
weigh-
ing
range
1602
