Siemens SIWAREX WP251 User Manual

Scale parameters and functions
8.26 DR 29 Configuration of technology messages
SIWAREX WP251
Manual, 12/2015, A5E37203357A
133
8.25.3
Sting selection for automatic logging
This parameter defines whether and, if so, which string is to be printed in the log. The
following options are available:
Function
code
Meaning
0 (default)
Log print without string
1 Log print with String 1
2
Log print with String 2
3
Log print with String 3
4
Log print with String 4
8.26
DR 29 Configuration of technology messages
The data record provides the option of selectively suppressing the technology messages of
WP251 (see section "Messages"). To suppress a message, the associated bit in DR 29 must
be reset.
Table 8- 26 Assignment of data record 29
Variable
Note
Type
Length
(bytes)
RW
De-
fault
Min.
Max.
Modbus
registers
Data record number Contains no. of the data record USHOR
T
2 r 29 - - 1812
Length Data record length information USHOR
T
2 r 16 - - 1813
Application Information on application to
which DR belongs
USHOR
T
2 r 105 - - 1814
Version identifier Current data record version
information
USHOR
T
2 r 1 1 65535 1815
2000 Technological
error
At least one technology error
exists (group error)
B16_0 0 rw 1 0 1 1816
2001 Timeout tare or
zero setting
Taring or zero setting is not
possible because a standstill
was not reached during the
standstill waiting time
B16_1 0 rw 1 0 1 1816
2002 Trace error The configured cycle for the
trace recording cannot be pro-
cessed: Reading is active or
buffer is full; recording is
stopped
B16_2 0 rw 1 0 1 1816
2003 Initial zero set-
ting on not possible
The weight at switch-on is out-
side the permissible initial zero-
ing range
B16_3 0 rw 1 0 1 1816
2004 Trace memory
full
Cyclic trace recording canceled
because memory is full
B16_4 0 rw 1 0 1 1816
-
-
B16_5
0
rw
1
0
1
1816
