Scale parameters and functions
8.19 DR 20 Single set point
SIWAREX WP251
Manual, 12/2015, A5E37203357A
109
8.19
DR 20 Single set point
8.19.1
Overview
The set point amount to be dosed is specified in the data record.
Procedure
● Specify the desired set point
● Transfer DR 20 to SIWAREX WP251
Table 8- 19 Assignment of data record 20
Variable
Note
Type
Length
(bytes)
Rw
De-
fault
Min
.
Max.
Modbus
registers
Data record
number
Contains no. of the
data record
USHORT 2 r 20 - - 1624
Length Data record length
information
USHORT 2 r 20 - - 1625
Application Information about
which application
the data record
belongs to
USHORT 2 r 105 - - 1626
Version identifi-
er
Current data record
version information
USHORT 2 r 1 1 6563
5
1627
Single set point
(Page 109)
Set point for a single
dosing
FLOAT 4 rw 50.0 0 Lim-
ited
in DR
25
1628
Reserve
Reserve
FLOAT
4
rw
-
-
-
1630
Reserve
Reserve
USHORT
2
rw
-
-
-
1632
Reserve
Reserve
USHORT
2
rw
-
-
-
1633
8.19.2
Single set point
The set point defines the weight to be dosed for a single dosing. It is specified based on the
weight unit set in DR 3 and must not exceed the maximum permissible set point from DR 25.
