Siemens SIWAREX WP251 User Manual

Scale parameters and functions
8.9 DR 8 date and time
SIWAREX WP251
Manual, 12/2015, A5E37203357A
95
8.9
DR 8 date and time
The weighing module has its own hardware clock. The current date and time are specified by
or read from data record DR 8. The clock is buffered with a capacitor and can continue
operating for up to approximately 70 hours without supply voltage.
If you are using the Modbus protocol, data record DR 48 must be used for the date and time
because the SIMATIC DTL format is not supported by Modbus.
Table 8- 8 Assignment of data record 8
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Data record
number
Contains no. of the data
record
USHORT 2 r 8 - - 1334
Length Data record length infor-
mation
USHORT 2 r 16 - - 1335
Application Information about which
application the DR belongs
to
USHORT 2 r 105 - - 1336
Version identifi-
er
Current data record version
information
USHORT 2 r 1 1 65635 1337
Date and time SIMATIC DTL format DTL 12 rw DTL#197
0-01-01-
00:00:00.
0
- - 1338
8.10
DR 9 module information
No inputs can be made in data record DR 9. The data record contains information about the
firmware and hardware versions of the module.
Table 8- 9 Assignment of data record 9
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Data record num-
ber
Contains no. of the data
record
USHORT 2 r 9 - - 1344
Length Data record length infor-
mation
USHORT 2 r 68 - - 1345
Application Information about which
application the DR belongs
to
USHORT 2 r 105 - - 1346
Version identifier Current data record version
information
USHORT 2 r 1 1 65635 1347
Order No. - head-
er
Maximum and current string
length for the order number
UBYTE[2] 2 r 16,16 - - 1348
Order No. Order number of the module
7MH ..
CHAR[16] 16 r "7MH4960
-6AA01"
- - 1349
