Siemens SIWAREX WP251 User Manual

Scale parameters and functions
8.30 DR 34 ASCII weight display
SIWAREX WP251
150 Manual, 12/2015, A5E37203357A
8.29.2
Operating errors, technology messages, data/command errors
All available message bits are presented in the table above. For data/command errors, there
is also "Additional information" available, which is described in more detail in section
"Messages" (see Errors and messages (Page 163)).
8.30
DR 34 ASCII weight display
8.30.1
Overview
DR 34 provides an ASCII string with 16 characters, that can be used as a weight display.
The string contains both the current gross/net weight after rounding according to DR 3 as
well as the weight unit. In addition additional parameters and weight values can be
(temporarily) displayed or hidden via a command.
For applications requiring official calibration, DR 34 cannot be used as a main display. In this
case, the "SecureDisplay" software must be used in order to represent the weight and
additional information in a calibratable manner.
The corresponding registers are always currently available at the Modbus end. For operation
with a SIMATIC CPU, DR 34 must be read or requested by WP251 via a command.
Table 8- 30 Assignment of data record 34
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus regis-
ters
Data record num-
ber
Contains no. of the data
record
USHORT 2 r 34 - - 4000
Length Data record length infor-
mation
USHORT 2 r 26 - - 4001
Application Information about which
application the DR belongs
to
USHORT 2 r 105 - - 4002
Version identifier Current data record version
information
USHORT 2 r 1 1 65635 4003
ASCII string header Maximum length and actual
length of string
UBYTE[2
]
2 r 16,16 - - 4004
ASCII string (page
119)
Weight display string CHAR[16
]
16 r " " - - 4005
8.30.2
Content of the display string
The following values can be displayed:
Standard display (gross/net weight) (via command 710)
From DR 30
High-resolution gross/net weight (via command 701 for 5 seconds)
From DR 30
