Scale parameters and functions
8.7 DR 6 Limits
SIWAREX WP251
84 Manual, 12/2015, A5E37203357A
Reserve Reserve DINT 4 rw 0 0 maxi-
mum
num-
ber
1246
Limit value 1 ON, limit
value 2 ON, limit
value 1 OFF, limit
value 2 OFF
Switch-on point for
Limit 2
FLOAT 4 rw 0 maxi-
mum
num-
ber
maxi-
mum
num-
ber
1248
Reserve Reserve DINT 4 rw 0 0 maxi-
mum
num-
ber
1250
Limit value 1 ON, limit
value 2 ON, limit
value 1 OFF, limit
value 2 OFF
Switch-off point for
Limit 2
FLOAT 4 rw 0 maxi-
mum
num-
ber
maxi-
mum
num-
ber
1252
Switch-on delay limit
3 (empty)
Switch-on delay
Limit 3 (ms)
TIME 4 rw 0 0 maxi-
mum
num-
ber
1254
Limit 3 - empty
(Page 85)
Limit "empty" ON
(always references
the gross weight).
Unit is dependent
on "Limit refer-
FLOAT 4 rw 0 maxi-
mum
num-
ber
range
maxi-
mum
num-
ber
range
1256
Switch-on/off delay
limit 1 & 2
Switch-on and
switch-off delay for
limit 1 and 2 (ms)
TIME 4 rw 0 0 maxi-
mum
num-
ber
1258
Limit value 1 ON, limit value 2 ON, limit value 1 OFF, limit value 2 OFF
The switch-on and switch-off points can be specified separately for each limit as a
percentage of the measuring range or as absolutely values (based on "Limit reference"
parameter setting). This allows both minimum and maximum value violation monitoring with
hysteresis. A delay time for switch-on and switch-off can also be specified. Either the current
net weight or the current gross weight can be selected as the reference value for limits 1 and
2.
