8.32 DR 38 Min/max pointer
SIWAREX WP251
152 Manual, 12/2015, A5E37203357A
8.32
DR 38 Min/max pointer
Data record 38 provides a non-volatile min/max pointer of the gross weight (filtered by filter
F1) that indicates the maximum weight that has occurred since commissioning or since a
reset of the min/max pointer. A time stamp is stored in parallel with the weight value. The
min/max pointer can be reset by the following commands: "Load factory settings (11)", "Load
standard parameter (12)" and "Reset min/max pointer (443)".
Table 8- 32 Assignment of data record 38
Variable
Note
Type
Length
(bytes)
Rw
De-
fault
Min.
Max.
Modbus
registers
Data record
number
Contains no. of the
data record
USHORT 2 r 38 - - 4051
Length
Data record length
information
USHORT 2 r 36 - - 4052
Application Information about
which application
the DR belongs to
USHORT 2 r 105 - - 4053
Version identifi-
er
Current data rec-
ord version infor-
mation
USHORT 2 r 1 1 65635 4054
Min/max pointer Gross weight
min/max pointer
FLOAT 4 r 0 - - 4055
Date and time
Date and time
DTL
12
r
-
-
-
4057
Reserve
Reserve
USHORT
2
r
-
-
-
4063
Reserve
Reserve
USHORT
2
r
-
-
-
4064
Reserve
Reserve
FLOAT
4
r
-
-
-
4065
Reserve
Reserve
FLOAT
4
r
-
-
-
4067
8.33
DR 39 Statistics
Data record 39 provides a variety of statistical data. The statistics can be reset at any time
with the "Reset statistics (442)" command.
Table 8- 33 Assignment of data record 39
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Data record number Contains no. of the
data record
USHORT 2 r 39 - - 4069
Length Data record length
information
USHORT 2 r 108 - - 4070
Application Information about
which application the
DR belongs to
USHORT 2 r 105 - - 4071
Version identifier Current data record
version information
USHORT 2 r 1 1 65635 4072
