Siemens SIWAREX WP251 User Manual

Scale parameters and functions
8.36 DR 46 Protocol content
SIWAREX WP251
Manual, 12/2015, A5E37203357A
157
8.36
DR 46 Protocol content
8.36.1
Overview
Log data is provided in data record DR 46.
Table 8- 37 Assignment of data record 46
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
regis-
ters
Data record num-
ber
Contains no. of the data
record
USHORT 2 r 46 4316
Length Data record length in-
formation
USHORT 2 r 152 4317
Application Information about which
application the DR be-
longs to
USHORT 2 r 105 4318
Version identifier Current data record
version information
USHORT 2 r 1 1 65635 4319
Oldest report ID
(Page 158)
Oldest protocol ID, 0: No
entry available
ULONG 4 r 0 1 4,294,967,295 4320
Newest report ID
(Page 158)
ID of last saved protocol
entry, 0: No entry availa-
ble
ULONG 4 r 0 1 4,294,967,295 4322
Selected protocol-
ID (Page 158)
ID of subsequent log
entry, 0: No entry availa-
ble
ULONG 4 r 0 1 4,294,967,295 4324
Reserve
Reserve
UBYTE[2]
2
r
12,12
4326
Reserve
Reserve
CHAR[12]
12
r
" 0"
" 1"
"4294967295"
4327
Reserve
Reserve
UBYTE[2]
2
r
12,12
4333
Reserve
Reserve
CHAR[12]
12
r
" 0"
" 1"
"4294967295"
4334
Reserve
Reserve
UBYTE[2]
2
r
12,12
4340
Reserve Reserve CHAR[12] 12 r " 0" " 1" " 4294967295" 4341
String header for
protocol ID cur-
rently selected
String header UBYTE[2] 2 r 28,28 4347
Protocol
(Page 158)
Log content CHAR[46] 46 r " " 4348
String header for
checksum
String header for check-
sum
UBYTE[2] 2 r 4,4 4371
Checksum Checksum of selected
log
CHAR[4] 4 r "0000" 4372
String header for
date
String header for date UBYTE[2] 2 r 10,10 4374
Date, time
(Page 159)
Date CHAR[10] 10 r "2012-03-
31"
4375
