Scale parameters and functions
8.25 DR 28 Additional strings for log
SIWAREX WP251
132 Manual, 12/2015, A5E37203357A
8.25
DR 28 Additional strings for log
8.25.1
Overview
Data record 28 provides the option of defining four user-definable text strings with 16
characters each. A selection code is used to define which of the four text strings are to be
written in the log. For example, four material names can be predefined and the appropriate
material name for a batch can be selected and logged.
Table 8- 25 Assignment of data record 28
Variable
Note
Type
Length
(bytes)
RW
Default
Min
.
Max.
Modbus
registers
Data record number
Contains no. of the data record
USHORT
2
r
28
-
-
1768
Length Data record length information USHORT 2 r 88 - - 1769
Application Information on application to
which DR belongs
USHORT 2 r 105 - - 1770
Version identifier Current data record version
information
USHORT 2 r 1 1 65535 1771
String 1 string
header
Maximum length and actual
length of string
UBYTE 2 rw 16,16 0 0 1772
String 1
String 1 for logging
CHAR
16
rw
0
0
0
1773
String 2 string
header
Maximum length and actual
length of string
UBYTE 2 rw 16,16 0 0 1781
String 2
String 2 for logging
CHAR
16
rw
0
0
0
1782
String 3 string
header
Maximum length and actual
length of string
UBYTE 2 rw 16,16 0 0 1790
String 3
String 3 for logging
CHAR
16
rw
0
0
0
1791
String 4 string
header
Maximum length and actual
length of string
UBYTE 2 rw 16,16 0 0 1799
String 4
String 4 for logging
CHAR
16
rw
0
0
0
1800
Sting selection for
automatic logging
(Page 133)
String selection for logging
0: No string
1: String 1
2: String 2
3: String 3
4 String 4
USHORT 2 rw 0 0 0 1808
Reserve
Reserve
USHORT
2
rw
0
0
0
1809
Reserve
Reserve
FLOAT
4
rw
0
0
-
1810
8.25.2
Strings 1, 2, 3 and 4
Four user-definable text strings with 16 characters each are available.
