Scale parameters and functions
8.27 DR 30 Process state
SIWAREX WP251
Manual, 12/2015, A5E37203357A
135
2116 Set point too
large
In removal mode there is not
enough material in the contain-
er at the start of dosing (gross <
set point) Dosing can still be
started in this case with the
"Continue weighing" command
and ended using "Rest empty-
ing" as soon as no more mate-
rial can be removed from the
B17_7 1 rw 1 0 1 1817
2096 Restore point set Recovery point has been suc-
B17_12 0 rw 1 0 1 1817
2097 Restore point
loaded
Recovery point (or default val-
ues, if no recovery point) has
B17_13 0 rw 1 0 1 1817
2098 Standard param-
eters loaded
Note for the user that the
standard parameters were
B17_14 0 rw 1 0 1 1817
2099 Factory settings
Note for the user that the facto-
B17_15 1 rw 1 0 1 1817
DR 30 Process state
8.27.1
This data record contains all weight values and related status information of WP251. All
values are read-only.
Note
Data record DR 30 does not have to be read into the PLC via a command! In data record DR
14
(page 101), the user can select two process variables that will be transmitted
-I/O to the CPU and be available there. In addition, the AWI
utomatic
eighing
nstrument) Status is available cyclically in the I/O (see section
tegration in SIMATIC") and can thus be directly used in the PLC program. At the Modbus
end, the parameters and status information from DR 30 is always current and the registers
can therefore be read immediately.
