Scale parameters and functions
8.11 DR 10 Load cell parameters
SIWAREX WP251
Manual, 12/2015, A5E37203357A
97
Application
Information about which
application the DR belongs
USHORT
2
r
105
-
-
1402
Current data record version
information
USHORT
2
r
1
1
65635
1403
Number of support
Number of support points USHORT 2 rw 0 0 8 1406
Load cell characteristic
value (Page 98)
1)
Characteristic value of the
connected load cell(s). The
mean value (mV) is used if
there is more than one cell.
FLOAT 4 rw 2 > 0.1 10 1408
Rated load of a load cell
(Page 98)
1)
Nominal load of one load cell FLOAT 4 rw 60 0
Specifi-
cation
from
1412
Reserve 3 Reserve USHORT 2 rw 0 - - 1419
Load cell manufacturer
String header UBYTE[2] 2 rw 24,24 1422
Load cell order number
String header UBYTE[2] 2 rw 24,24 1435
1)
Parameter for calculation of calibration points with theoretical calibration
If no anchor points are used, the number of support points is equal to the number of load
cells.
If anchor points are used in addition to load cells, the number of support points is equal to
the total number of load cells and fixed support points.
A tank is mounted on three load cells → Number of mechanical support points = 3
