Siemens SIWAREX WP251 User Manual

Scale parameters and functions
8.8 DR 7 Process interfaces
SIWAREX WP251
90 Manual, 12/2015, A5E37203357A
Variable
Note
Type
Length
(bytes)
RW
Default
Min.
Max.
Modbus
Register
Trace storage
method
(Page 94)
0: Trace recording runs
as a circular buffer
1: Trace is stopped when
the trace memory is full
BIT 0 rw 0 0 1 1325.16
Bit 1
Reserve
BIT
0
rw
0
0
1
1325.15
Bit 2
Reserve
BIT
0
rw
0
0
1
1325.14
Bit 3
Reserve
BIT
0
rw
0
0
1
1325.13
Bit 4
Reserve
BIT
0
rw
0
0
1
1325.12
Bit 5
Reserve
BIT
0
rw
0
0
1
1325.11
Bit 6
Reserve
BIT
0
rw
0
0
1
1325.10
Bit 7
Reserve
BIT
1
rw
0
0
1
1325.9
Bit 8
Reserve
BIT
0
rw
0
0
1
1325.8
Bit 9
Reserve
BIT
0
rw
0
0
1
1325.7
Bit 10
Reserve
BIT
0
rw
0
0
1
1325.6
Bit 11
Reserve
BIT
0
rw
0
0
1
1325.5
Bit 12
Reserve
BIT
0
rw
0
0
1
1325.4
Bit 13
Reserve
BIT
0
rw
0
0
1
1325.3
Bit 14
Reserve
BIT
0
rw
0
0
1
1325.2
Bit 15
Reserve
BIT
1
rw
0
0
1
1325.1
Reserve 1
Reserve
LONG
4
rw
0
0
-
1326
Reserve 2
Reserve
FLOAT
4
rw
0
0
-
1328
8.8.2
Assignment of digital input DI.0, DI.1, DI.2, DI.3
A command trigger can be assigned to a digital input. The assignment is made using the
corresponding command code: → Command lists (Page 179).
Function assignment of input DI.0, DI.1, DI.2, DI.3:
Function code
(decimal)
Assignment
0
Not assigned
1 … 32759
Command code is triggered at a positive edge (0 → 1 transition)
32760...32767 Transition for steps 0 to 7 (positive edge)
32769…65527 Command code +32768: Command is triggered at a negative edge (1 → 0 transi-
tion)
65528...65535
Transition for steps 0 to 7 (negative edge)
