Siemens SIWAREX WP251 User Manual

Technical specifications
13.2 Electrical, EMC and climatic requirements
SIWAREX WP251
Manual, 12/2015, A5E37203357A
207
Mechanical requirements and data
Table 13- 11 Technical specifications: Mechanical requirements and data
Testing
Standards
Test values
Vibrational load during
operation
IEC 61131-2
IEC 60068-2-6
Test Fc
5 to 8.4 Hz: 3.5 mm out.
8.4 to 150 Hz: 9.8 m/s
2
(=1G)
0 cycles per axis
1 octave / min.
Shock load during opera-
tion
IEC 61131-2
IEC 60068-2-27
Test Ea
150 m/s
2
(approx. 15 g), half sine
Duration: 11 ms
Quantity: 3 each per axis
in negative and positive direction
Vibration load during
transport
IEC 60068-2-6
Test Fc
5 to 8.4 Hz: 3.5 mm out.
8.4 Hz ... 500 Hz: 9.8 m/s
2
10 cycles per axis
1 octave / min.
Shock load during
transport
IEC 60068-2-27:
Test Ea
• 250 m/s
2
(25G), half sine
• Duration: 6ms
• Quantity: 1 000 each per axis
• in negative and positive direction
Free fall IEC 61131-2
IEC 60068-2-31:
Test Ec, procedure 1
• For devices < 10 kg:
• In product packaging:
300 mm drop height
• In shipping package:
1.0 m drop height
• per 5 attempts
13.2
Electrical, EMC and climatic requirements
Electrical protection and safety requirements
Table 13- 12 Requirements: Electrical protection and safety requirements
Met requirement
Standards
Comments
Safety regulations IEC 61010-1
IEC 61131-2; UL 508
CSA C22.2 No.142
Protection class IEC 61140 Module is operated with protective extra-
low voltage.
The protective conductor connection
serves only a functional earth to dissi-
pate interference currents
