Siemens SIWAREX WP251 User Manual

Scale parameters and functions
8.11 DR 10 Load cell parameters
SIWAREX WP251
96 Manual, 12/2015, A5E37203357A
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Serial number -
header
String header UBYTE[2] 2 r 12,12 - - 1357
Serial number
Serial number
CHAR[12]
12
r
" "
-
-
1358
Firmware type -
header
String header UBYTE[2] 2 r 2,2 - - 1364
Firmware type
Firmware type
CHAR[2]
2
r
'V'
-
-
1365
FW version 1st
position
Version 1. USHORT 2 r 0 - - 1366
FW version 2nd
position
Version 2. USHORT 2 r 0 - - 1367
FW version 3rd
position
Version 3. USHORT 2 r 0 - - 1368
Hardware version
number
HW version USHORT 2 r 1 - - 1369
OS version header
String header
UBYTE[2]
2
r
1,1
-
-
1370
OS version (load-
er) - designation
Operating system version CHAR[2] 2 r 'V' - - 1371
OS version (load-
er) - designation
e.g. version n USHORT 2 r 'V' - - 1372
Reserve
Reserve
USHORT
2
r
0
-
-
1373
Reserve
Reserve
USHORT
2
r
0
-
-
1374
Reserve
Reserve
USHORT
2
r
0
-
-
1375
Reserve Reserve FLOAT 4 r 0 - - 1376
8.11
DR 10 Load cell parameters
8.11.1
Overview
The load cell parameters must be assigned before the automatic calibration or calibration
check. The load cell manufacturer and the order number should always be specified so that
the information is available in a service case.
Table 8- 10 Assignment of data record 10
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Data record number Contains no. of the data
record
USHORT 2 r 10 - - 1400
Length Data record length infor-
mation
USHORT 2 r 44 - - 1401
