Siemens SIWAREX WP251 User Manual

Scale parameters and functions
8.22 DR 23 Material parameters
SIWAREX WP251
118 Manual, 12/2015, A5E37203357A
8.22
DR 23 Material parameters
8.22.1
Overview
Material-specific parameters are specified in the data record.
Table 8- 22 Assignment of data record 23
Variable
Note
Type
Length
(bytes)
RW
Default
Min.
Max.
Modbus
registers
Data record
number
Contains no. of the data record USHORT 2 R 20 - - 1672
Length Data record length information USHORT 2 R 20 - - 1673
Application Information about which applica-
tion the data record belongs to
USHORT 2 R 105 - - 1674
Version
identifier
Current data record version infor-
mation
USHORT 2 R 1 1 65635 1675
Parameter
relation
(Page 119)
0: Trailing/fine weight is interpret-
ed as % of set point (DR 20) (de-
fault)
1: Trailing/fine weight is interpret-
ed as absolute weight value
USHORT 2 RW 0 0 1 1676
Reserve
Reserve
USHORT
2
RW
-
-
-
1677
Fine weight
(Page 119)
Material quantity that is to be
dosed in fine flow
FLOAT 4 RW 20 0 - 1678
Trailing
weight
(Page 119)
Material quantity that still runs
after shut-off of the fine flow
FLOAT 2 RW 5 0 - 1680
Blocking
time coarse
signal
(Page 120)
Blocking time after switch-off of
coarse signal
TIME 4 RW 0 0 1682
Blocking
time fine
signal
(Page 120)
Blocking time after switch-off of
fine signal
TIME 4 RW 0 0 1684
Shut-off
correction
weight
(Page 121)
Shut-off correction value for com-
pensation of influences such as
overpressure or underpressure
when dosing
FLOAT 4 RW 0 0 - 1686
Reserve
Reserve
FLOAT
4
RW
-
-
-
1688
Reserve
Reserve
FLOAT
4
RW
-
-
-
1690
Reserve
Reserve
USHORT
2
RW
-
-
-
1692
Reserve
Reserve
USHORT
2
RW
-
-
-
1693
