AUX Menu Operations 151
No.
Parameter
Adjustment
1
Transition Rate
Transition rate
Chapter
8
Color
Backgrounds,
Copy
and
Swap,
and
Other
Settings
Setting the transition rate
To set the M/E transition rate
For example, to make the settings for the M/E-1 bank, use
the following procedure.
1 In the status area if the Misc >Transition >Key/ME/
FTB menu (3231), press [M/E-1].
2 In the <Transition Rate> group, press [Transition].
3 Set the number of frames.
No.
Parameter
Adjustment
1
Transition Rate
Transition rate
Notes
When a clip transition is selected as the transition type, it
is not possible to change the transition rate in this menu.
To set the independent key transition rate
For example, to make the settings for keys 1 to 4 in the
M/E-1 bank, use the following procedure.
1 In the status area if the Misc >Transition >Key/ME/
FTB menu (3231), press [M/E-1].
2 In the <Transition Rate> group, press [Key K1-K4].
To insert (on) or remove (off) keys individually, press
[Key(On) K1-K4] or [Key(Off) K1-K4].
3 Set the number of frames.
No.
Parameter
Adjustment
1
Key1 Trans Rate
Key 1 transition rate
2
Key2 Trans Rate
Key 2 transition rate
3
Key3 Trans Rate
Key 3 transition rate
4
Key4 Trans Rate
Key 4 transition rate
Setting the fade-to-black transition rate
1 In the Misc >Transition >Key/ME/FTB menu (3231),
press [FTB].
2 Set the number of frames.
AUX Mix Transition Settings
For details about AUX mix transition operations,
1 “AUX Mix Transitions” (p. 78).
Enabling AUX mix transitions
1 Open the Misc >Transition >Aux Mix menu (3232).
2 Select the AUX bus (odd-numbered bus) to be
configured.
3 Press [Aux Mix], turning it on.
To disable, press again to turn it off.
Setting the AUX mix transition rate
1 Open the Misc >Transition >Aux Mix menu (3232).
2 Select the target AUX bus (odd-numbered bus).
3 Set the number of frames.
No.
Parameter
Adjustment
2
Transition Rate
Transition rate
AUX Menu Operations
AUX Bus Settings
In the AUX menu, you can make color corrector settings
for an AUX bus.
Setting the AUX bus color corrector
In the Engineering Setup >Switcher >Key/Wipe/FM/CCR
>CCR menu (7335.3), you can make settings for an AUX
bus for which color correction is enabled.
Notes
The target even-numbered buses cannot be selected when
AUX mix transitions are enabled.
1 In the Aux >Aux Bus menu (2311), select the AUX
bus to which the settings apply.
2 In the <CCR> group, press [CCR], turning it on.
3 Make the following settings, as required.
