Sony ICP-6530 User Manual

USO RESTRITO
Settings Relating to Video Switching 355
Chapter
19
Switcher
Setup
Notes
If you change any of the following parameter values,
the name display position will change on all
subscreens. You cannot adjust the name display
position for each subscreen.
No.
Parameter
Adjustment
2
Name
Position H
Horizontal position
3
Name
Position V
Vertical position
Assigning signals to the subscreens
1 Open the Engineering Setup >Switcher >Output
>Multi Viewer >Source/Output Assign menu
(7333.10).
2 Select the target subscreens in the list on the left.
3 If assigning an input signal to a subscreen, press
[Source] in the <Source/Output Select> group.
If assigning an output signal, press [Output].
4 Select the signal you want to assign from the list on the
right.
Notes
If [Output] is selected in step 3, the following signals
cannot be used.
• Signals output from connectors assigned to Out 1 to
xx (where “xx” is 16 (MVS-6520/3000A), 24
(MVS-6530), or 12 (MVS-3000))
• Multi Viewer 1 and 2
• FC Output 1 and 2
• DME Monitor 1 and 2
5 Press [Set].
2 In the list on the left, select a pair of odd-numbered and
even-numbered output connectors (for example, 11
and 12).
3 In the list on the right, select the AUX bus combination
to use.
To disable the AUX mix transition, select [Disable].
4 Press [Set].
5 Repeat steps 2 to 4, as required.
6 Press [Execute].
Settings Relating to Video
Switching
Selecting the Bank to Make the
Settings
In the Engineering Setup >Switcher >Transition menu
(7334), select the bank to which the settings apply, then
make the settings.
Setting the transition preview mode
In the <Transition Preview> group of the Engineering
Setup >Switcher >Transition menu (7334), select either of
the following.
One Time: The transition preview ends after a single
transition.
Normal: Switching the [TRANS PVW] button on or off
switches between the transition preview mode and the
normal mode.
Selecting the independent key transition
Enabling AUX Mix Transitions
An AUX mix transition ( 1 p. 78) is enabled when AUX
buses are grouped and assigned to consecutive odd-
numbered and even-numbered output connectors.
Notes
When AUX mix transitions are enabled, color correction
(Bus CCR) for AUX bus pairs is controlled using the odd-
numbered bus settings.
1 Open the Engineering Setup >Switcher >Output >Aux
Mix menu (7333.12).
mode of the transition control block
In the <Key Transition> group of the Engineering Setup
>Switcher >Transition menu (7334), select either of the
following.
Same: The transition settings for the On and Off directions
are the same.
Independ: The transition settings for the On and Off
directions can be set separately.
Selecting the background transition flip-
flop mode
In the Engineering Setup >Switcher >Transition menu
(7334), press [Bus Toggle] to switch between on and off.
On: Flip-flop mode
