AUX bus cross-point selection in the cross-point control block
Cross-point selection in the router
Cross-point selection in the cross-point control block
Auto transition and take in the transition control block
Cut in the transition control block
Transition type selection
Auto transition and take in independent key transitions
Key insertion and deletion in independent key transitions
Selection of independent key transition type
VTR/DDR/clip start point setting
VTR/DDR/clip fast forward
Disk recorder/Extended VTR file recall
File Name
Set the file name as follows.
Example: nnnnnnnn.PNL_rrrr.PMR
nnnnnnnn: In a file created on the switcher, this is a
register name automatically set by the switcher.
The name is limited to eight characters.
The following characters may not be used.
space, \, /, :, ;, , (comma), . (dot), <, >, *, ?, ", |
rrrr: Macro register number (0001 to 0099)
Removable disk Any directory
MACRO
CTRLCPU
nnnnnnnn.PNL_rrrr.PMR
Path example: Removable Disk\Sample\MACRO\
Saving and Recalling a File
For a newly created file, if you create a directory on a
removable disk (see figure below), and move the file to the
prescribed location, you can then recall it in the File >All,
External File menu.
Notes
When amending a file saved on the switcher, be sure to
save it in the original directory.
CTRLCPU\nnnnnnnn.PNL_rrrr.PMR
Errors
If any of the following problems occur, it is not possible to
recall the file. Attempting to recall the file will produce an
error message.
•
If there is a syntax error.
•
If a required parameter is not present.
For details about error messages,
1
“Error Messages”
(p. 434).
Correspondence between Events and Symbols
For details about events,
1
“Events” (p. 281).
