Cross-Point Settings
1
Press [User Color Select].
The User Color Select menu (7322.12) appears.
2
Select the object to set in the “Target” field on the left.
3
Select the desired color in the “Color” field on the
right.
The selected color is displayed in the list on the left.
4
Repeat steps 2 and 3 above to change colors, as
required.
5
Press [Execute].
Chapter
18
Control
Panel
Setup
3 In the <Source Color> group, press one of [User Color
1] to [User Color 3].
To change the color assigned to User Color 1 to 3
Copying Cross-Point Assign Tables
The contents of a cross-point assign table can be copied to
another cross-point assign table, and vice versa.
Notes
The contents of a sub table cannot be copied to the main
table.
1 Open the Engineering Setup >Panel >Xpt Assign
>Table Copy menu (7322.8).
2 Select the copy source and copy destination table
numbers.
3 Press [Copy].
4 Check the message, then press [Yes].
3 Press [Table Assign Set].
Exporting Source Names and
Destination Names
To send the source names and destination names to the S-
Bus, use the following procedure.
1 Open the Engineering Setup >Panel >Xpt Assign
>Name Export menu (7322.9).
2 Set the destination station ID.
No.
Parameter
Adjustment
1
Station ID
Station ID setting
a)
a) If set to 255, the information is sent to all stations (with display of
“All”).
3 Press [Src Name Export].
This exports the source names to the station selected in
step 2.
4 Press [Dest Name Export].
This exports the destination names to the station
selected in step 2.
Notes
Since destination names cannot be selected freely,
fixed names are used.
Making Settings for Audio Mixer
Linking the audio mixer
Selecting Cross-Point Assign Tables
You can select the cross-point assign table to be used for
the M/E-1 or PGM/PST bank.
Notes
It is not possible to assign cross-point tables 5 to 14 to a bus
of a switcher operated by an MKS-8080/8082 AUX Bus
Remote Panel.
1 In the Engineering Setup >Panel >Xpt Assign menu
(7322), select the bank or bus.
2 Select a table.
Notes
For audio mixer operations in this system, it is necessary
to set Mixer ESAM-II for the DCU 9-pin serial port.
For details, 1 “Serial Port Settings” (p. 369).
1 In the Engineering Setup >Panel >Xpt Assign menu
(7322), select the bank or bus.
2 Press [Audio Follow].
“Enable” appears in the “Audio Follow” column.
Setting the audio mixer cross-points
To assign an audio mixer cross-point to a switcher cross-
point pair (video/key), carry out the following procedure.
