USO RESTRITO
184
Applying Special Effects (Overall Signal Effects)
No.
Parameter
Adjustment
1
V/K H
Horizontal defocusing of video
and key signals
2
V/K V
Vertical defocusing of video and
key signals
3
V/K All
Horizontal and vertical
defocusing of video and key
signals
4
Video All
Horizontal and vertical
defocusing of video signal
5
Key All
Horizontal and vertical
defocusing of key signal
No.
Parameter
Adjustment
1
H
Horizontal defocusing of video
and key signals
2
V
Vertical defocusing of video and
key signals
3
All
Horizontal and vertical
defocusing of video and key
signals
Chapter
10
DME
Operations
To invert the regions of the two colors
In the Color Mix menu (4117), press [Color Invert],
turning it on.
Adjusting color 1 and color 2
1 In the Color Mix menu (4117), press [Color1] and
[Color2] to adjust colors 1 and 2 respectively.
2 Set the following parameters.
No.
Parameter
Adjustment
1
Luminance
Luminance
2
Saturation
Saturation
3
Hue
Hue
Modifying the color combination pattern
See the following pages.
1 “Setting the aspect ratio of the wipe crop pattern
(Aspect)” (p. 182)
1 “Replicating the wipe crop pattern (Multiplication)”
(p. 183)
1 “Rotating the wipe crop pattern (Rotation)” (p. 182)
1 “Applying modulation to the wipe crop pattern
(Modulation)” (p. 182)
Video: Video signal only
Key: Key signal only
Notes
[Key] can only be selected when using the MVE-
8000A or MVE-9000.
4 Set the following parameters.
When Video/Key is selected using the MKS-6570
No.
Parameter
Adjustment
1
H
Horizontal defocusing of video
and key signals
2
V
Vertical defocusing of video and
key signals
3
All
Horizontal and vertical
defocusing of video and key
signals
When Video/Key is selected using the MVE-8000A/
9000
Parameter group [1/2]
Applying Special Effects
(Overall Signal Effects)
Defocus Settings
Applying the Defocus effect
1 Open the DME >Video Modify >Defocus/Blur menu
(4121).
2 Press [Defocus], turning it on.
Notes
On the MKS-6570 and MVE-8000A, the Defocus and
Glow effects cannot be enabled at the same time. The
effect that was turned on most recently is enabled.
3 In the <Defocus Mode> group, select the signal to
which to apply the Defocus effect.
Video/Key: Video signal and key signal
Parameter group [2/2]
No.
Parameter
Adjustment
1
Video H
Horizontal defocusing of video
signal
2
Video V
Vertical defocusing of video
signal
3
Key H
Horizontal defocusing of key
signal
4
Key V
Vertical defocusing of key signal
When Video is selected
