Sony ICP-6530 User Manual

USO RESTRITO
408
Menus of Disabled Operations and Settings
Appendix
Menu
Disabled operation/setting
Number
Path
7333.5
Engineering Setup >Switcher
>Output >4:3 Crop
Output 17 to 32 settings
7333.10
Engineering Setup >Switcher
>Output >Multi Viewer >Source/
Output Assign
• When setting the [Src No] parameter: M/E-2 signal, Primary 33 to 48
signal selection
• When setting the [Output No] parameter: Output 17 to 32 selection
7333.11
Engineering Setup >Switcher
>Output >FC Output Select
Output 17 to 32 selection
7333.12
Engineering Setup >Switcher
>Output >Aux Mix
Output 17 to 24 settings
7334
Engineering Setup >Switcher
>Transition
M/E-2 settings
7334.1
Engineering Setup >Switcher
>Transition >Preset Color Mix
• M/E-2 settings
• [Key5] to [Key8] selection
7334.2
Engineering Setup >Switcher
>Transition >Transition Curve
M/E-2 settings
7335
Engineering Setup >Switcher >Key/
Wipe/FM/CCR
M/E-2 settings
7335.1
Engineering Setup >Switcher >Key/
Wipe/FM/CCR >Show Key
[M/E2 PVW] settings
7336.2
Engineering Setup >Switcher >Link
>Internal Bus Link >Link Bus Select
• Selection of items related to M/E-2
• Selection of items related to P/P Key5 to 8
7336.5
Engineering Setup >Switcher >Link
>GPI Link >GPI Link Adjust
• M/E-2 Auto Trans, M/E-2 Cut selection on video/button display
• M/E-2 bus settings on bus display
7336.6
Engineering Setup >Switcher >Link
>M/E Link
M/E-2 selection
7336.7
Engineering Setup >Switcher >Link
>Key Transition Link
• Selection of items related to M/E-2
• Selection of items related to P/P Key5 to 8
7337.2
Engineering Setup >Switcher
>Device Interface >GPI Input
• [M/E-2] selection
• Selection of following items on [P/P] (x=5 to 8):
DSKx Cut, DSKx Auto Trans, DSKx SS ? Recall
7337.4
Engineering Setup >Switcher
>Device Interface >GPI Output
• [M/E-2] selection
• Selection of following items when Trigger Type is not set to Status in
[P/P] (x=5 to 8): DSKx Cut, DSKx Auto Trans, DSKx SS ? Recall
• Selection of following items when Trigger Type is set to Status in [P/P]
(x=5 to 8): DSKx On
Disabled Menus (MVS-3000)
The following menus display functions and items that are
not supported by the MVS-3000. These are disabled, even
if the item is selected or a value specified, and do not affect
device operation.
Menu
Disabled operation/setting
Number
Path
1115
M/E-1 >Key1 >Processed Key/
Resizer
a)b)
[DME1], [DME2], [Override] settings
1115.1
M/E-1 >Key1 >Processed Key/
Resizer >Monitor
a)b)
All menu operations
1116.4
M/E-1 >Key1 >Transition >DME Wipe
Adjust >1ch Pattern Select
a)
Selection of unsupported patterns
c)
