USO RESTRITO
Setup 23
Chapter
1
Overview
Macro timelines
By recording macro recalls and execute actions on a
timeline, in the same way as for keyframes in an effect,
you can automatically execute them in a sequence.
Macro attachments
Macro attachment is a function whereby a macro register
is assigned to a control panel button or a particular position
of a fader lever, linking the execution of the button
function or a fader lever operation with a macro execution.
For details, see Chapter 15 “Macros” ( 1 p. 281).
Router/tally setup (Router/Tally)
For details, see Chapter 22 “Router Interface and Tally
Setup” ( 1 p. 373).
User setup (User Setup)
For details, see Chapter 23 “User Setup” ( 1 p. 378).
File Operations
You can save register data, including setup information
and snapshot information, as a file on a local disk or
removable disk, and recall it as required.
Regarding frame memory, it is possible to capture image
data stored in an external device into frame memory. You
can also convert the format of image data in frame memory
into a different format and save it in an external device.
For details, see Chapter 16 “Files” ( 1 p. 302).
Setup
Various settings are required, in order to operate the
switcher, control panel, DME, external devices, and so on,
connected together in a single system.
This is referred to as “setup,” and you can carry out the
setup operations from the Engineering Setup menu
(hereinafter, the Setup menu). The settings are grouped
under the following headings.
System setup (System)
For details, see Chapter 17 “System Setup” ( 1 p. 313).
Panel setup (Panel)
For details, see Chapter 18 “Control Panel Setup”
( 1 p. 325).
Switcher setup (Switcher)
For details, see Chapter 19 “Switcher Setup” ( 1 p. 345).
DME setup (DME)
For details, see Chapter 20 “DME Setup” ( 1 p. 363).
DCU setup (DCU)
For details, see Chapter 21 “DCU Setup” ( 1 p. 366).
