Appendix
Wipe Pattern List
Wipe Pattern List
Interpreting the illustrations for patterns
The black part of the pattern represents the old video, and the white part the new video, with the wipe taking place in the
direction of the arrow.
1 2 3 4 5 6 7 8 9 10
11 12 13 14 15 16 17 18 19 20
21 22 23 24
DME Wipe Pattern List
DME wipe patterns available in one-channel mode
Slide
1001 1002 1003 1004 1005 1006 1007 1008
Split
1011 1012 1013
To Next Page
