Number of source signals to be
selected
Chapter
18
Control
Panel
Setup
Set: Deletes the signal currently assigned to the
selected button number and makes a new
assignment.
Insert: Moves the signal currently assigned to the
selected button number to the next number, and
makes a new assignment.
If a button number above 121 is selected, see “Notes”
in step
5
in “Creating the main table”
(
1
p. 329).
To disable a button
Select the button you want to disable, and press [Inhibit].
To delete an assigned signal
Select the button for the signal you want to delete, and
press [Delete] in the <Button Assign> group.
The signal assigned to the button number next to the
selected button number moves up one line.
If a button number above 121 is selected, see “Notes” in
“To delete an assigned signal”
(
1
p. 330).
Shift All Bus: When this is On, it functions as a shift
button for all buses. When this is Off, it functions as a
shift button for the source name display section.
Notes
•
It is not possible to make this setting separately for each
of the M/E and PGM/PST banks.
•
[Shift All Bus] is only valid when the cross-point button
shift operation (see previous item) is set to [Lock] or
[Off].
Setting the source signal name
1
Open the Engineering Setup >Panel >Xpt Assign >Src
Name/Src Color menu (7322.6).
2
Select the signal to be set.
Returning the table to its default state
1
In the Engineering Setup >Panel >Xpt Assign >Main,
V/K Pair Assign menu (7322.5) or Engineering Setup
>Panel >Xpt Assign >Table Button Assign menu
(7322.1), press [Default Recall].
2
Check the message, then press [Yes].
Setting the cross-point button shift
operation
You can set the operation of the rightmost button in each
row of cross-point buttons, excluding the reentry buttons.
In the <Xpt Shift Mode> group of the Engineering Setup
>Panel >Xpt Assign >Main, V/K Pair Assign menu
(7322.5) or Engineering Setup >Panel >Xpt Assign >Table
Button Assign menu (7322.1), select one of the following
for each cross-point table.
Hold: Acts as a shift button, and the shifted version of the
cross-point buttons is enabled while the button is held
down.
Lock: Acts as a shift button, and pressing the button
toggles between the shifted version and the unshifted
version.
Off: Acts as cross-point button 24 (16 on the ICP-3016).
Setting the action of the [SHIFT] button in
the cross-point control block
The function of the shift button is set in the <Display Shift
Mode> group of the Engineering Setup >Panel >Xpt
Assign >Main, V/K Pair Assign menu (7322.5) or
Engineering Setup >Panel >Xpt Assign >Table Button
Assign menu (7322.1).
3
Press [Source Name].
4
Enter a name of not more than 16 characters, then
press [Enter].
Sequential names for multiple signals
When you specify a number at the end of a signal name, all
of the signals in the range selected are automatically
assigned names ending with sequential numbers.
Example: To assign sequential names to source signal 2
through source signal 4
1.
In step 2 above, set the [Source No] parameter to
“2,” and set the [Num] parameter to “3.”
2.
Set the name of source signal 2 to “CAM2.”
The name “CAM3” is assigned automatically to
source signal 3, and the name “CAM4” is assigned
automatically to source signal 4.
Setting the Cross-point Button Color
for Each Signal
You can set the color of cross-point buttons for
background A bus and background B bus on the M/E and
P/P banks.
1
Open the Engineering Setup >Panel >Xpt Assign >Src
Name/Src Color menu (7322.6).
2
Select the signal to be set.
