1-4. Service Tools/Measuring Equipment List
1-4-1. Service Tools
Part No. Name Usage/note
Commercially available Grayscale chart (reflective type) (16 : 9) For camera adjustment
Commercially available Star chart (reflective type)
J-6394-080-A Grayscale chart (transparent type) (16 : 9)
J-6029-140-B Pattern box PTB-500
Supplied with this unit Mini USB cable For firmware update
J-6325-110-A Bit for torque driver (M1.4/M1.7) For tightening screws
J-6325-380-A Bit for torque driver (M2)
J-6326-120-A Hexagon bit (width across flats: 1.5)
J-6325-400-A Torque driver (3 kg•cm) (0.3 N•m)
J-6252-510-A Torque driver (6 kg•cm) (0.6 N•m)
J-6611-290-A BOX driver (Width across 11 mm) For tightening hexagon nuts
7-432-114-11 Locking compound 200 g For preventing screws from being loosened
7-651-000-10 Sony (SGL-601) 50 g grease Lubricant
1-4-2. Measuring Equipment
Use the following calibrated equipment or equivalent for adjustments.
Equipment Model name
Oscilloscope Tektronix TDS3054 or equivalent (150 MHz or more)
HD waveform monitor LEADER ELECTRONICS CORP.LV5152DA or equivalent
Frequency counter Advantest TR5821AK or equivalent
Digital voltmeter Advantest TR6845 or equivalent
Color monitor Sony HDM-20E1U/14E1U/14E5U or equivalent
Luminance meter Konica Minolta LS-110 or equivalent
PMW-300
1-13
