ENGINE 3-55
CLUTCH COVER
OIL SEAL INSPECTION
Inspect the oil seal lip for wear and damage. If any defects are
found, replace the oil seal with a new one.
OIL SEAL REMOVAL
• Remove the oil seal retainer 1.
• Remove the oil seal 2 with the special tool.
09913-50121: Oil seal remover
OIL SEAL INSTALLATION
• Install a new oil seal 1 with the special tool.
09913-70210: Bearing installer set (10 – 75 )
• Install the oil seal retainer.
• Apply a small quantity of grease to the oil seal lip.
99000-25010: SUZUKI SUPER GREASE “A”
or equivalent
