SERVICING INFORMATION 10-27
TIGHTENING TORQUE
ENGINE
ITEM N·m kgf-m lbf-ft
Engine mounting bolt 41 4.1 29.5
Engine mounting upper plate nut 40 4.0 29.0
Engine mounting lower plate nut 28 2.8 20.0
Exhaust pipe bolt 23 2.3 16.5
Muffler mounting bolt Front 23 2.3 16.5
Rear 50 5.0 36.0
Muffler connecting bolt 23 2.3 16.5
Exhaust pipe cover screw 4 0.4 3.0
Cylinder head cover bolt/nut 11 1.1 8.0
Cylinder head nut 37 3.7 27.0
Camshaft sprocket bolt 10 1.0 7.0
Primary drive gear nut
100 10.0 72.5
Crank balancer bolt 40 4.0 29.0
Cam chain tension adjuster bolt 10 1.0 7.0
Cam chain tensioner bolt 10 1.0 7.0
Generator rotor nut 160 16.0 115.5
Starter clutch bolt 26 2.6 19.0
TDC plug 21 2.1 15.0
Generator cover plug 15 1.5 11.0
Valve clearance adjusting screw lock-nut 15 1.5 11.0
Oil gallery plug 23 2.3 16.5
Oil drain plug 23 2.3 16.5
Engine sprocket nut 90 9.0 65.0
Clutch sleeve hub nut 55 5.5 40.0
Clutch spring set bolt 10 1.0 7.0
Clutch cover bolt 11 1.1 8.0
Crankcase bolt 11 1.1 8.0
Generator cover bolt (M6) 11 1.1 8.0
(M5) 6 0.6 4.5
PAIR pipe bolt/nut 10 1.0 7.0
Oil pump mounting bolt 10 1.0 7.0
Spark plug 18 1.8 13.0
Gearshift cam stopper plug 23 2.3 16.5
Gearshift arm stopper 19 1.9 13.5
Gearshift lever mounting bolt 10 1.0 7.0
