Suzuki TU250X User Manual

9-32 ELECTRICAL SYSTEM
BRAKE LIGHT/TAILLIGHT
Brake light/taillight: 12 V 21/5 W 1

BRAKE LIGHT/TAILLIGHT BULB REPLACEMENT
• Remove the lens by removing the screws.
• Push in on the bulb, turn it counterclockwise, and pull it out.
If you touch the bulb with your bare hands, clean the bulb with a cloth moistened with alcohol
or soapy water to prevent premature bulb failure.
* Do not use bulb other than those with predetermined wattage.

Suzuki TU250X Specifications

General

Displacement	249 cc
Bore x Stroke	72.0 mm x 61.2 mm
Compression Ratio	9.2:1
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Drum brake
Front Tire	90/90-18 M/C 51S, tube type
Rear Tire	110/90-18 M/C 61S, tube type
Overall Length	2070 mm (81.5 in.)
Overall Width	750 mm (29.5 in.)
Overall Height	1075 mm (42.3 in.)
Seat Height	770 mm (30.3 in.)
Ground Clearance	165 mm (6.5 in.)
Wheelbase	1375 mm (54.1 in.)
Curb Weight	148 kg (326 lbs.)
Engine Type	4-stroke, single cylinder, SOHC
Front Brakes	Single disc
Fuel Capacity	12 L (3.2 US gal.)
