General| Displacement | 249 cc |
|---|---|
| Bore x Stroke | 72.0 mm x 61.2 mm |
| Compression Ratio | 9.2:1 |
| Ignition | Electronic ignition (transistorized) |
| Starter | Electric |
| Transmission | 5-speed constant mesh |
| Final Drive | Chain |
| Front Suspension | Telescopic, coil spring, oil damped |
| Rear Suspension | Swingarm type, coil spring, oil damped |
| Rear Brakes | Drum brake |
| Front Tire | 90/90-18 M/C 51S, tube type |
| Rear Tire | 110/90-18 M/C 61S, tube type |
| Overall Length | 2070 mm (81.5 in.) |
| Overall Width | 750 mm (29.5 in.) |
| Overall Height | 1075 mm (42.3 in.) |
| Seat Height | 770 mm (30.3 in.) |
| Ground Clearance | 165 mm (6.5 in.) |
| Wheelbase | 1375 mm (54.1 in.) |
| Curb Weight | 148 kg (326 lbs.) |
| Engine Type | 4-stroke, single cylinder, SOHC |
| Front Brakes | Single disc |
| Fuel Capacity | 12 L (3.2 US gal.) |
