EXHAUST SYSTEM 6-3
• Remove the exhaust pipe/muffler 5 by removing the mount-
ing bolt and nut.
NOTE:
Support the muffler to prevent it from falling.
• Remove the exhaust pipe gasket 6.
• Remove the exhaust pipe cover 7.
• Loosen the muffler connecting bolt 8.
• Remove the exhaust pipe 0 from the muffler 9.
• Remove the HO2 sensor A.

* Be careful not to expose the HO2 sensor to exces-
sive shock.
* Do not use an impact wrench while removing or
installing the HO2 sensor.
* Be careful not to twist or damage the HO2 sensor
lead wire.

Suzuki TU250X Specifications

General

Displacement	249 cc
Bore x Stroke	72.0 mm x 61.2 mm
Compression Ratio	9.2:1
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Drum brake
Front Tire	90/90-18 M/C 51S, tube type
Rear Tire	110/90-18 M/C 61S, tube type
Overall Length	2070 mm (81.5 in.)
Overall Width	750 mm (29.5 in.)
Overall Height	1075 mm (42.3 in.)
Seat Height	770 mm (30.3 in.)
Ground Clearance	165 mm (6.5 in.)
Wheelbase	1375 mm (54.1 in.)
Curb Weight	148 kg (326 lbs.)
Engine Type	4-stroke, single cylinder, SOHC
Front Brakes	Single disc
Fuel Capacity	12 L (3.2 US gal.)
