Suzuki TU250X User Manual

PERIODIC MAINTENANCE 2-15
BRAKE FLUID LEVEL
• Keep the motorcycle upright and place the handlebars
straight.
• Check the brake fluid level by observing the lower limit line on
the front brake fluid reservoir.
• When the brake fluid level is below the lower limit line, replen-
ish with brake fluid that meets the following specification.
 Specification and classification: DOT 4

BRAKE FLUID REPLACEMENT
8-13
Inspect every 5 000 km (3 000 miles, 15 months).
Replace every 2 years.
* The brake system of this motorcycle is filled with a
glycol-based brake fluid. Do not use or mix different
types of fluid such as silicone-based and petro-
leum-based fluids. Do not use any brake fluid taken
from old, used or unsealed containers. Never reuse
brake fluid left over from the last servicing or stored
for a long period of time.
* Brake fluid, if it leaks, will interfere with safe running
and immediately discolor painted surfaces. Check
the brake hoses and hose joints for cracks and fluid
leakage before riding.

Suzuki TU250X Specifications

General

Displacement	249 cc
Bore x Stroke	72.0 mm x 61.2 mm
Compression Ratio	9.2:1
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Drum brake
Front Tire	90/90-18 M/C 51S, tube type
Rear Tire	110/90-18 M/C 61S, tube type
Overall Length	2070 mm (81.5 in.)
Overall Width	750 mm (29.5 in.)
Overall Height	1075 mm (42.3 in.)
Seat Height	770 mm (30.3 in.)
Ground Clearance	165 mm (6.5 in.)
Wheelbase	1375 mm (54.1 in.)
Curb Weight	148 kg (326 lbs.)
Engine Type	4-stroke, single cylinder, SOHC
Front Brakes	Single disc
Fuel Capacity	12 L (3.2 US gal.)
