Tektronix MSO5204B Printable Help

TekProbe component Description
ADA400A 100X, 10X, 1X, and 0.1X, high gain differential amplifier
P5100A 2.5 kV, 100X, 250 MHz high voltage passive probe
P6015A 40 kVpk, 1000X, 75 MHz high voltage single-ended passive probe
TCPA300, TCPA400 Current measurement systems amplifier (requires TPA-BNC)
■
TekVPI
TekVPI component Description
TAP1500 1.5 GHz active single-ended voltage probe
TAP2500 2.5 GHz active single-ended voltage probe
TCP0020 50 MHz, 20 A AC/DC current probe
TCP0030A DC to 120 MHz, 30 A AC/DC current probe
TCP0150 DC to 20 MHz, 150 A AC/DC current probe
TDP0500 500 MHz active differential voltage probe
TDP1000 1 GHz active differential voltage probe
TDP1500 1.5 GHz active differential voltage probe with ±8.5 V differential input voltage
TDP3500 3.5 GHz differential voltage probe with ±2 V differential input voltage
TPP0502 500 MHz 2X TekVPI passive voltage probe
TPP0850 2.5 kV 800 MHz TekVPI high-voltage passive probe
TPP500, TPP1000 10X Passive Probes are compact with 10X attenuation, designed for use with
Tektronix MSO/DPO4000B and MSO/DPO5000B Series instruments.
The bandwidth (–3 dB) for TPP500 is 500 MHz.
The bandwidth (–3 dB) for TPP1000 is 1 GHz.
THDP0100 ±6 kV, 100 MHz high-voltage differential probe
THDP0200 ±1.5 kV, 200 MHz high-voltage differential probe
TMDP0200 ±750 V, 200 MHz high-voltage differential probe
P5100A 2.5 kV, 500 MHz, 100X high-voltage passive probe
DPO7000C
■
BNC
BNC component Description
CT1, CT2, CT6 Current probes, AC high-speed
P6021, P6022 Current probes, AC
■
TekProbe
TekProbe component Description
ADA400A Differential preamplifier
P5100A High-voltage probe
P6015A High-voltage probe
P6139B Passive probe
About Tektronix oscilloscopes
6 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
