LAN server status control window
From the Utilities menu, select LAN Server Status.
Overview
This control window allows you to enable the VXI-11 LAN server to accept GPIB commands.
For more information, see the Getting Started with OpenChoice Solutions manual that shipped with your instrument.
To use
â–
Click the Start button to enable the VXI LAN server to accept GPIB commands.
â–
Click the Stop button to disable the ability of the VXI-11 LAN server to accept GPIB commands.
What do you want to do next?
Return to the Utilities Menu.
Learn about oscilloscope analysis and connectivity.
Learn about GPIB Configuration Control Window.
External signals control window
From the Utilities menu, select External Signals, or click the Ext Ref button on the Acquisition tab of the Horizontal/Acquisition
control window.
Overview
Use the External Signals control window to select the signal to send to the Aux Out BNC connector, or to toggle the instrument
clock reference source.
NOTE. The following illustrations show C model instruments. On MSO/DPO70000DX model instruments the External Reference
In maximum input voltage is 4 V and the impedance is 50 Ω. On DPO70000SX model instruments the External Reference In
maximum input voltage is 2.8 V
p-p
and the impedance is 50 Ω.
Utilities
550 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
