Set up an SPI bus trigger
NOTE. The SPI Bus Trigger type is available on instruments with option SR-EMBD.
From the Trig menu, select SPI Setup.
NOTE. This online help documents features and options available for several instrument models. Your instrument may not have
every feature discussed in this online help, depending on its configuration.
Overview. Use the controls in this window to set up the SPI trigger parameters.
To use. For information on the controls, click the buttons.
■
Trigger Type
■
Settings
■
SS Source
■
SCLK Source
■
SS / SCLK Data.. Active
■
Thresholds
■
Trigger On
■
MISO / MOSI.. Source
Trigger setups
DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 427
