Before startup. All instruments in a multi-Instrument configuration must be connected properly before powering on the

instruments. If the configuration is changed after the instruments are powered on, a system restart may be required.

If an instrument is not connected in a multi-instrument configuration, the instrument powers on in its stand alone mode, not multi-

instrument mode.

UltraSync

™

bus cable. An UltraSync bus cable will connect any multi-instrument configuration capable instrument.

All cables must be connected to the instruments prior to power up. A restart will be required if the instruments are turned on

before the cables are connected.

About Tektronix oscilloscopes

DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 49

Default Chapter5
