TL-WA7510N 5GHz 150Mbps Outdoor Wireless Access Point User Guide
121
Click the Delete All button to delete all entries.
Click the Next button to go to the next page and Click the Previous button to return to the
previous page.
)
Note:
1. When the trigger connection is released, the corresponding opened ports will be closed.
2. Each rule can only be used by one host on the LAN at a time. The trigger connection of other
hosts on the LAN will be refused.
3. Incoming Ports ranges cannot overlap each other.
5.9.3 DMZ
Choose menu “Forwarding > DMZ”, and then you can view and configure DMZ host in the screen
as shown in Figure 5-49.
The DMZ host feature allows one local host to be exposed to the Internet for a special-purpose
service such as Internet gaming or video-conferencing. DMZ host forwards all the ports at the
same time. Any PC whose port is being forwarded must have its DHCP client function disabled
and should have a new static IP Address assigned to it because its IP Address may be changed
when using the DHCP function.
Figure 5-49 DMZ
¾ To assign a computer or server to be a DMZ server:
1. Click the Enable button.
2. Enter the IP address of a local PC that is set to be DMZ host in the DMZ Host IP Address
field.
3. Click the Save button.
