TL-WA7510N 5GHz 150Mbps Outdoor Wireless Access Point User Guide
5
Chapter 2 Connecting the Device
2.1 System Requirements
¾ Each PC in the LAN needs a working Ethernet Adapter and an Ethernet cable with RJ45
connectors.
¾ TCP/IP protocol must be installed on each PC.
¾ Web browser, such as Microsoft Internet Explorer 5.0 or later, Netscape Navigator 6.0 or
later.
¾ If the device is configured to AP client router mode, you also need:
Wireless Internet Access Service (WISP).
¾ If the device is configured to AP router mode, you also need:
Broadband Internet Access Service (DSL/Cable/Ethernet).
¾ One DSL/Cable Modem that has an RJ45 connector (you do not need it if you connect the
router to the Ethernet.).
2.2 Installation Environment Requirements
¾ Operating temperature: -30℃~70℃
¾ Operating Humidity: 10%~90% RH, Non-condensing
2.3 Connecting the Device
To connect the AP, please follow the steps below:
1. Power off your PC, Cable/DSL Modem, and the AP.
2. Locate an optimum location for the AP. The best place is usually at the center of your wireless
network. The place must accord with the Installation Environment Requirements.
3. Adjust the direction of the antenna. Normally, upright is a good direction.
After finishing the steps above, please choose the operation mode you need and carry out the
corresponding steps. There are three operation mode supported by this AP: Standard AP, AP
Router, and AP Client Router.
2.3.1 Standard AP Mode
In this mode, the device enables multi-users to access, and provides several wireless modes,
including Access Point, Multi-SSID, Client, Repeater, Universal Repeater, and Bridge with AP.
These six modes are illustrated as below:
