TL-WA7510N 5GHz 150Mbps Outdoor Wireless Access Point User Guide
75
Chapter 5 Configuring AP Router & AP Client Router Mode
This chapter will show each Web page's key functions and the configuration way in AP Router
mode as well as AP Client Router mode.
)
Note:
The setting Web pages of these two modes are mostly the same, with only three differences:
1. In AP Router Mode, there is one more WAN connection type, Big Pond Cable, than that in AP Client
Router Mode.（See Section 5.6.2
）
2. In AP Client Router Mode, there is one more submenu under Wireless main menu, Antenna
Alignment, than that in AP Router Mode, as shown in Figure 5-24 & Figure 5-25. (See Section 5.7
)
3. The Wireless Settings page in AP Router mode and that in AP Client Router mode are something
different, as shown in Figure 5-26 & Figure 5-27. (See Section 5.7.1
)
5.1 Login
Open your web browser. Type in the default address http://192.168.1.254 in the address field of
web browser and then press Enter.
Figure 5-1 Login to the Device
Enter admin for the User Name and Password (both in lower case letters) in Figure 5-2 below.
Then click OK or press Enter.
Figure 5-2 Login Windows
