CNT-SVN01C-EN 65
Chapter 12
Setting up the
operator display
This chapter shows how to calibrate the operator-display touch screen
and how to adjust the brightness and contrast. To set up the operator dis-
play screens and security, see the Tracer MP580/581 Programmable Con-
troller Programming guide (CNT-SVP01C-EN).
CAUTION
Equipment damage!
To clean the operator display, use a cloth dampened with commercial
liquid glass cleaner. Spraying water or cleansers directly on the screen
may result in equipment damage.
Calibrating the operator display
To calibrate the operator display:
1. On the home screen, press the Setup button. The Setup menu
appears.
2. Press the page down button to view the next screen.
3. Press the Calibrate Touch Screen button. A calibration screen
appears.
CAUTION
Equipment damage!
Do not allow the operator display to come in contact with sharp
objects.
4. Touch the target using a small, pliable, blunt object, such as a pencil
eraser. Hold until the beeping stops. A second calibration screen
appears.
5. Again, touch the target with the object. Hold until the beeping stops.
The Setup menu appears.
6. Press the Home button. The home screen appears.
