Chapter 12 Setting up the operator display
66 CNT-SVN01C-EN
Setting up time and date
To change the time for the operator display:
1. On the home screen, press the Setup button. The Setup menu
appears.
2. Press the Change Time button to view the next screen.
3. Using the buttons, type the time using the format hh:mm, where hh
is the hour and mm is the minute. Press either the AM or PM button,
as appropriate.
4. If you make a mistake, press Clear and start again. To accept the
changes, press OK.
To change the date for the operator display:
1. On the home screen, press the Setup button. The Setup menu
appears.
2. Press the Change Date button to view the next screen.
3. Press the forward and back arrows to move the cursor from day to
month to year. Use the buttons to type the appropriate date.
4. If you make a mistake, press the Reset button. To accept the changes,
press OK.
Adjusting brightness and contrast
To adjust the brightness and contrast of the operator display:
1. On the home screen, press the Setup button. The Setup menu
appears.
2. Press the page down button to view the next screen.
3. Press the Adjust Brightness and Contrast button. The Brightness and
Contrast screen appears.
4. To increase the brightness, press the buttons along the top row, in
sequence, from left to right. To decrease the brightness, press the
buttons from right to left.
5. To increase the contrast, press the buttons along the bottom row, in
sequence, from left to right. To decrease the contrast, press the
buttons from right to left.
6. Press the Home button. The home screen appears.
Note:
Contrast adjustment is not available on all computer display
models.
