Uponor Smatrix Base User Manual

Pos. Description
A
Weekdays, press one of the days to show or modify
the schedule for that day
B
Weekday not yet programmed (Modify only)
C
Weekday selected for viewing or programming
D
Programmed weekday
E
Programmed Comfort mode
F
Programmed ECO mode
G
Cancel settings and go to previous menu
H
Scroll programmed schedules left
I
Programmed schedule name
J
Modify programmed schedule (only shown for
Custom schedule)
K
Scroll programmed schedules right
L
Confirm changes and go to previous menu
M
Position of programming marker, 30 minute interval
(Modify only)
N
Program ECO mode for marked 30 minute interval
(Modify only)
O
Move marker left (Modify only)
P
Reset the custom schedule to default values
(Modify only)
Q
Time of day for programming marker (Modify only)
R
Copy a schedule from other program (Modify only)
S
Move marker right (Modify only)
T
Program Comfort mode for marked 30 min interval
(Modify only)
aCtivate a Programmed sChedule
To select an ECO profile:
1. Go to the ECO profile menu.
1.1 For a single room:
Home screen > Room information > Room
settings > ECO profile.
1.2 For the whole system:
Home screen > Main menu > System
settings > ECO profile.
2. Use buttons < and > [H and K] to select a profile.
The profile name is displayed at position I.
3. Confirm and save with the green check mark [L].
modif y Custom Profile
To modify the custom ECO profile for a room:
1. Go to the ECO profile menu.
1.1 For a single room:
Home screen > Room information > Room
settings > ECO profile.
1.2 For the whole system:
Home screen > Main menu > System
settings > ECO profile.
2. Use buttons < and > [H and K] to select the
Custom profile. The profile name is displayed at
position I.
3. Press Modify [J].
4. Select (press) a weekday [C].
5. Use buttons < and > [O and S] to move the marker
[M] to a the time of the day.
6. Press button N or T to set the selected 30 minute
interval to ECO [N] or Comfort [T] mode. The
marker moves automatically to the next 30 minute
interval.
TIP! Press the button repeatedly to quickly set a
large block of time.
7. Repeat step 5 and 6 until the selected weekday is
set.
8. Repeat steps 4 to 7 until the whole week is set.
9. Confirm and save with the green check mark [L].
UK
CZ
DE
DK
EE
ES
FI
FR
HR
HU
IT
LT
LV
NL
NO
PL
PT
RO
RU
SE
SK
109
UPONOR SMATRIX BASE/BASE PRO · INSTALLATION AND OPERATION MANUAL
