DS1093-162A 28
1. Input router’s IP address from IE-based browser to open the Router configuration interface shown as above;
2. Click [Transmittal rule] option to take you to the port forwarding instructions for your router;
3. The DVR IP address for the intranet should be <192.168.1.101>, you should forward server port and web port to
this IP address respectively.
4. Now user can visit the DVR remotely.
Friendly Reminder: The router’s port forwarding interface may be different, however, when entering into virtual server,
user will always need forward port (range: 1025~65535) of router to IP address of DVR allocated or automatically
captured, and select [All] or [Both] in corresponding protocol column and save the above setting.
Above steps may differ from the router device depending on the manufacturer.
2.4.4.3 Sub stream
Go to [Main menuNetworkSub Stream] to enter into the interface shown as below:
• Video: allow you open or close the sub stream output in CIF Resolution. If you select “Enable” system will select
sub-stream preview and guarantee image quality once network is unstable.
• Frame rate: allow you set net transmittal frame rate. User could select the relative value by pull-down menu.
• Bit rate: allow you set net transmittal bit rate. User could select the relative value by pull-down menu.
• Audio: When tick-selecting the option, system will record video and audio simultaneously.
Note:
In Sub Stream it is possible to set a max. Frame Rate value up to 5FPS for all channels, except for a single channel
where it is possible to set the max. Frame rate value up to 25FPS.
2.4.4.4 Email set
Click [Main MenuNetworkEmail] option to enter into the email set interface shown as below.
SSL: is a security link transport protocol. You can encrypt your communication info (including your email) using SSL
to prevent hackers from monitoring your email or communication info and even your password.
Please set SSL to “On” via Gmail.com server, and set to “Off” via other mail server.
