DS1093-162A 41
2.8 START/STOP CRUISE
If multiple presets are specified, the PTZ camera will automatically move to the entire preset one at a time whilst user
activates [Start Cruise ] options. If you want to stop cruise, please click [ ] icon on the [Tool] column.
2.9 DIGITAL ZOOM
This option allows to select a channel in full screen mode and zoom in on the image in LIVE mode. By right clicking on the
channel displayed in full screen mode, it is possible to select the option DIGITAL ZOOM.
Now it is possible to select the area to be enlarged with the mouse, by keeping the left button pressed and dragging the
area. On the bottom right the user can see in a window the whole channel images with the area to be enlarged, selected in
a red box. To disable this function, right click.
2.10 RECORD SEARCH
You could enter into [Record Search] menu from Pop-up menu conveniently and quickly and search/playback the record
histories. Record search details are introduced previously in Section 2.4.3.1.
2.11 START/STOP MANUAL RECORD
You can start manual record function, or you also can click [ ] button on the Front panel or Remote controller to activate
manual record. Please stop record manually once you activate manual record.
To stop record quickly, please click the icon [ ] or [Stop] button on the front panel or remote controller.
2.12 START/STOP SEQUENCE
In the single mode, when entering into [Start sequence] menu, auto-sequence will be conducted at the set interval.
Details please refer to section 2.4.1.2.
2.13 PIP MODE
You can display a Picture-in-Picture in live mode. PIP has two display modes, including 1X1 display mode and 1X2 display
mode.
2.14 MUTE
Click the [ ] icon, or press <Mute> button on the front panel and Remote controller to control the mute of DVR.
2.15 REBOOT AND SHUT DOWN
It is possible to Reboot or Shut Down the DVR from Pop-up Menu.
1x1 display mode 1x2 display mode
