DS1093-162A 39
2.4.8.2 Exceptions
Click [Main menuAdvancedEvent] to enter into the <Event> interface shown as below
• Event Type: support the three abnormal types: Disk No Space, Disk Error and Video Loss.
• Enable Exception: allow you activate abnormal alarm.
• Alarm out: allow you connect external alarm sensor. Select [Enable] or [Disable].
• Alarm Out Time: you can set how long the external sensor alarm will last when the exception is detected (10sec,
20sec, 40sec, and 60sec);
• Show icons: You can set show the icon on the screen when the exception is detected. About icons type please refer
to Section 4.
• Buzzer time: you can set how long the buzzer will sound when the exception is detected (OFF, 10sec, 20sec, 40sec,
60sec);
• Send Email: Allows you set the alarm images is issued to a specified email.
Event Type Function
HDD Loss
/ HDD No Space
When Hard Drive is not detected (HDD damage, power supply malfunction), or HDD auto-overwrite
is off, and free space is not enough, an alarm will be triggered.
Video Loss
Sends alarm when DVR can’t receive video signal (such as camera damage, cable broken or
damaged or power supply malfunction).
2.4.8.3 FTP
This function is applied together with alarming function. The captured images or alarming recording can be uploaded to
FTP server through network.
FTP: Enable or disable the function.
Server IP: Put the FTP Server Address.
Port: FTP service port，default value is 21.
Nome Utente: User name for visiting FTP
Password: Password for visiting FTP
Nome Dir: Directory Name in order to transfer the pictures or record alarms.
