DS1093-162A 44
3.2.1 MENU BAR
Menu bar include [Live], [Replay], [Configuration], [Path Configuration] and [Logout] options
3.2.2 LIVE DISPLAY
After running the Web Application Manager on your local PC, system will be defaulted to enter into <Live> interface shown
as above. You can click [Play] button to Open/close live images and enter into on-spot record and Capture, quad, 9-split or
16-split mode by operating the control bar on the bottom of screen.
Volume switch
Record icon: record will be saved to a specified position after starting record.
Snapshot function: allow you capture the live images and save it to a specified position. The image should be
saved as *.bmp format.
Clicking the icon will close/open the current channel’s live mode
Or click the right key of mouse on each <Live> window to pop up the interface shown as below.
Show bit rate: show current bit rate;
Original Proportions: show original proportions.
: CH Display mode
: Allow you open all the <live> channels.
: Allow you close all the <live> channels.
: Display previous channels
: Display next channels
: Click the icon to enlarge current window to full screen; right-click to pop-up menu options, now allow you
select <Exit full screen>
